12/24 UNC fog tips 0.02in (0.50mm) orifice middle pressure mister nozzle

.50mm orifice middle pressure mister nozzle is a spray device, by spraying liquid to form steam or atomized substances, widely used in industrial production, agricultural irrigation, environmental protection and other fields. The main function of the .50mmorifice middle pressure mister nozzle is to disperse the original liquid into fine particles, forming fine particles, in the field of misting, usually involved in the particle size range between 1-200 microns with 0.05mm orifice .




Product details
High temperature casting High temperature casting process, good luster texture, toughness, high hardness, oxidation resistance is significant.
Strict material selection Strict material selection, high quality material casting, high temperature forging, one process, beautiful appearance, pay attention to quality
Adaptable 316 stainless steel for increased wear life and corrosion resistance.

Fine 0.50mm orifice mister nozzle humidification anti-drip spray uniform mist nozzle

Good density made of high quality materials, good hardness and hard quality
Fine use of high precision design to make careful density good

Applicable industries: Electronics, chemical, environmental protection, steel, machinery, painting, electroplating, prevention and control, automobile, paper, medicine, food and other industrial production fields of application: Wetting and rust removal, air humidification, chemical treatment, chemical agent spraying, liquid spraying, tobacco humidification, tablet coating, smoke evaporative cooling, sterilization and disinfection, component cooling, fruit spraying wax, ceramic tile glazing, wool spinning spray humidification.

12/24 UNC fog tips 0.02in .50mmorifice middle pressure mister nozzle

Thread sizes	orifices （mm）	pressure （bar）	flow （mL/Min）	spray angle（°）	Effective spray distance（M）	The spray distance（M）
12/24UNC	0.5	12	55.5	90	0.8	1.0
		15	78.0	100	1.1	1.4
		18	94.4	100	1.2	1.6
