0.3mm orifice 10/24 middle pressure mist nozzle

middle pressure misting nozzle 0.012in (0.30mm) orifice 10/24 UNC fog atomizing nozzles

Availability: In Stock

Orifice:0.012"(0.30mm)
Thread range:10/24 unc thread
Flow range: 35 ml/min at 12 bar
Pressure range:300 to 1000psi midle pressure range
Material of manufacture available: Stainless steel
Other Stock thread sizes:12/24 standard, 10/24, 1/8 , 1/4 available and others
Functional applications: Widely used in Cooling,Humidity,Dust control,Odor control,disinfection,Parks misting,Special Effect Mist-Fogging,Humidification reduces the temperature, etc.

Qty:

For More quantity price, customization, or other inquiries:

fast shipping

shipping by express,air,sea etc

quality guarantee

Advanced production technology

Online support

Engineer online consultations

middle pressure misting nozzle 0.012in (0.30mm) orifice 10/24 UNC fog atomizing nozzles
orifices （mm）	pressure （bar）	flow （mL/Min）	spray angle（°）	Effective spray distance（M）	The spray distance（M）
0.3	12	35.5	65	0.4	0.8
	15	44.5	70	0.8	1.3
	18	53.8	70	1.0	1.4

Thread sizes	orifices （mm）	pressure （bar）	flow （mL/Min）	spray angle（°）	Effective spray distance（M）	The spray distance（M）
10-24UNC	0.3	12	35.5	65	0.4	0.8
		15	44.5	70	0.8	1.3
		18	53.8	70	1.0	1.4
	0.4	12	48.5	75	0.4	0.6
		15	62.5	80	0.9	1.1
		18	80.7	80	1.2	1.6
	0.5	12	55.5	90	0.8	1.0
		15	78.0	100	1.1	1.4
		18	94.4	100	1.2	1.6
