The spacing of the mister nozzles of the patio misting system is appropriate.



When we choose to use patio misting spray, how much spacing is appropriate for the spray nozzles?


In the fog effect in the industry, misting zone layout is different from other misting system arrangement, misting zone is usually line distribution, the single nozzle spray distance is usually from 0.4 to 0.5 meters, so when we contact project, first asked if the customer is the perimeter of a field, or need to decorate the circumference of the misting area, rather than area. In this way, through the point line to line cover the surface, you can calculate the design of the whole misting belt needs to use how much specifications of the host.

For example, if a 10mx10m rectangular field needs to be equipped with fog effect, the first thing to be asked is its perimeter. When we know that the perimeter is 40m, we will consider how to arrange fog effect. Since the spray distance of the spray nozzle is 0.4 to 0.5m, the opposite side is normally selected for fog effect arrangement, and the fog effect can cover the whole rectangular area. Then the effective misting belt length is 20m. When we determine the length of the misting belt, we can arrange the spacing of the misting nozzle according to the requirements of the owner.

Generally, in the field of landscape construction, in order to ensure the concentration of fog effect, we usually choose a spray nozzle with a diameter of 0.15mm. When the requirement of fog effect concentration is high, the spacing between nozzles of 0.3m is selected for arrangement, and the fog effect concentration is thick and not easy to disperse. When the requirement of fog effect is low, 0.5m spacing is selected for layout. Good fog effect will not affect the sight line. When the spacing of sprinkler heads is 0.8m or above, the fog effect is sparse and easy to disperse.


In the field of daily temperature, misting effect of misting system requirements are usually not very high, the main thought is given priority to, cooling dust and fog effect is keep out the line of sight, so we will often go on the fog effect effect general drip nozzle, not only can reduce the concentration of the mist effect, while its drip tight design can effectively avoid water droplets spatter to the people. When the cooling or dust removal requirements are high, choose the spacing of 0.5m sprinkler heads for layout. When the anti-drip sprinkler heads with larger aperture are selected, the spacing of wider sprinkler heads can be selected, but it should not exceed 1m.


Calculate the length of the misting belt and the spacing of the nozzle, we can basically get the flow of the whole system, according to the flow can choose the corresponding host.
